Single-Shaft Shredder with Pressure Mechanism

Harris 2021-06-17

The single-shaft shredder is a machine used to finely shred materials. It is used for recycling. The most common materials for shredding on a single-shaft shredder are fibrous, such as: plastic, paper, textiles, wood, polymers, microcircuits boards and other waste.

Single Shaft Shredder

Working Principle of the Single-shaft Shredder

The processed material is fed into the receiving hopper, which is installed on the shredder's support frame. The raw materials to the bunker can be carried out both manually and mechanically. The material, entering the receiving hopper of the single-shaft shredder, is pressed by a hydraulic piston against the crushing roller, and the shreddinging roller shreds the material by breaking and cutting. To obtain the required size of finished product, a screen is installed under the shredder rotor. Depending on the customer's requirements, the size of the final material can be adjusted by changing the diameter of the holes in the grid.

To increase the service life, as well as increase the level of safety, the equipment is equipped with emergency sensors. If the limiting pressure on the cutting shaft is exceeded, the prepressor stops, ceasing to press on the material.

The single-shaft shredder can be used both autonomously and as part of technological lines.

Buy Single-Shaft Shreddeer

You can easily find the product catalog of our single-shaft shredder on our website. The most important thing is that we have the ability to customize the equipment for you according to your actual needs. If you need to buy any type of shredder, or need a quotation, please contact us, we are happy to help you at any time.
