The detachable container garbage collector, also known as pull arm garbage truck or hook arm garbage truck, has a load capacity of 1-30 tons and can be selected in various specifications. It adopts advanced technology, making the truck easy to operate and highly safe and reliable. The truck can be separated from the container, allowing for multiple containers and multiple uses for one truck. It is suitable for the transportation and unloading of garbage containers in various situations.
The detachable container garbage collector is composed of the truck chassis, pull arm main oil cylinder, attached frame, flipping frame, supporting legs (optional), locking frame, locking oil cylinder, multi-channel directional valve, etc.
The detachable container garbage collector can be directly driven to the garbage station. Through the control of the hydraulic system, the hook arm installed on the back seat of the garbage container can be lowered, and the connection point at the front end of the garbage container in the station can be hung. The garbage container can be pulled to the back seat of the truck body, and the truck can be started to transport the garbage to the garbage treatment station for self dumping.
The main load-bearing components are made of imported high-strength steel plates, which have high strength and long service life.
Adopting a one key linkage control method, there is no need for multiple operations, which can avoid tedious or erroneous operations.
Adopting imported PLC and electromechanical hydraulic integrated control, which is integrated, fully automated, and easy to operate.
The arm hook is equipped with a safety rod, and the large arm hook is supported by a rear iron wheel, ensuring stable and reliable performance.
The hydraulic integrated multi way valve adopts original imported products, with stable quality and high reliability.
A truck can be equipped with multiple containers, reducing the number of truck configurations, improving transportation efficiency, and reducing operating costs.
| Arm Hook Truck Model | Arm Hook Model | Loading Capacity (kg) | Adaptive Containers (m³) |
| 1 ton | CCA03 | 1000 | 2 |
| 1.5 tons | CCA1 | 1500 | 3 |
| 3 tons | CCA2 | 3000 | 5,6 |
| 5 tons | CCA5 | 8000 | 10,12 |
| 8 tons | CCA8 | 14000(12000) | 10,12 (Bulk container) 10,12 (Mobile container) |
| 17 tons | CCA010 | 21000 | 15,18 (Mobile container) 18,22 (Fixed container) |
| ＞17 tons | |||
| 25 tons | CCA25 | 30000 | 22 (Mobile container) 26-28 (Fixed container) |
Note: Technical specifications may change without notice due to ongoing technological advancements.
